W Type |
||
|---|---|---|
| Part Number | W-150-1 | |
| Family | Thermal Circuit Protector (Breaker) | |
| Category | W | |
| Series | W8 | |
| Voltage | 32VDC; 250VAC, 50/60 Hz | |
| Rated Current | 15A | |
| Mounting | Snap In Panel Mount | |
| Reset Type | T3, Manual Reset | |
| Reset Overload Capacity | Six times rated current for 0.25-2.0amp models Ten times rated current for 3-20amp models | |
| Interrupt Capacity | 1,000 A at 250VAC, 50/60 Hz | |
| RoHS | Y | |
| Standard Pack | 1000 | |
| Termination | 0.250 QC Tabs | |
W Type
Rated Current: 15A
Voltage: 32VDC; 250VAC, 50/60 Hz
Reset Type: T3, Manual Reset
