E513C |
||
|---|---|---|
| Part Number | E513C-20-4A5-00 | |
| Description | 20A | |
| Family | Thermal Circuit Protector (Breaker) | |
| Category | E5 | |
| Series | E513C | |
| Voltage | 14Vdc | |
| Rated Current | 20A | |
| Mounting | Horizontal (Crosswise) Mounting Bracket | |
| Reset Type | T1, Auto Reset | |
| Operating Temperature | -40ºC (-40ºF) to 85ºC (185ºF) | |
| Interrupt Capacity | 2,500A @ 14Vdc | |
| Dimension |
Length: 1.248" Width: 0.8" Height: 0.693" Unit: inch |
|
| Weight | 23 g | |
| Standard Pack | 300 | |
| Termination | #10-32 Thread | |
| Body | Metal | |
| Storage Temperature | -40ºC (-40ºF) to 125ºC (260ºF) | |
Length: 1.248"
Width: 0.8"
Height: 0.693"
Unit: inch
